OPERATING PRINCIPLE

• Senses near infrared light emitted from fiber optic cabling. A continuous red glow at the handle and an audible beeping noise (if not switched off) indicates the presence of near infrared light.

OPTICAL INTERFACE

• Non-contact ceramic ferrule. Fits directly with 1.25 mm LC receptacles. Tethered ferrule adapter for testing 1.25 mm ferrule patchcord. Supports single-mode, multimode, UPC and APC connectors and ports.

WAVELENGTH DETECTION

• 850 nm to 1625 nm

OPTICAL POWER DETECTION RANGE

• +3 dBm to -30 dBm

LIGHT DETECTION

• Visible steady red LED indicator when optical power is detected

LIGHTBEAT™ INDICATOR

• Flashes twice every two seconds when unit is on and battery strength is sufficient.

BATTERY SAVER

• Unit automatically turns off after five minutes of inactivity

BATTERIES

• 2 AAA alkaline batteries included

BATTERY LIFE

• Typically, greater than 1 year (5 hrs. of use a week)

ITEM SIZE

• 2.87” x 1.42” x 10.27” / 7.4 x 3.6 x 26.1 cm

OPERATING TEMPERATURE RANGE

• -10 °C to 50 °C

OPERATING HUMIDITY RANGES

• 95 % (10 °C to 35 °C) Non-condensing 75 % (35 °C to 40 °C) Non-condensing uncontrolled < 10 °C

OPERATING ALTITUDE ≤ 3000 meters

STORAGE TEMEPERATURE -20 °C to 50 °C
